C-Series Downlights ML-C16-1325-M

ML-C16-1325-M


Find a stockist Chat to Specialist

Product Information

Overview

Switchable wattage, multi CCT

Features

Multi CCT white, neutral white and warm white

Tech Specs

Total power consumed

13/16/18/20/25W

Lumen output

WW 2750lm | NW 3100lm | W 3000lm (at max wattage 25W)

Colour temperature

3000K (Warm White)
4000K (Neutral White)
5700K (White)

CRI

80

UGR

13W UGR<19, 16-25W UGR<22

Efficacy

WW 115lm/W | NW 135lm/W | W 130lm/W

IP rating

IP54 front, IP40 rear

Dimmable

No

Beam angle

60º

Power supply

220-240VAC External,isolated driver

Power factor

0.9

Input Current

0.14A

Inrush Current

Up to 7 x Input current

Operating Temperature

-20°C to 40°C

Average life

50,000hrs**

Dimensions

Ø 190mm x D 61mm | Cut-out 160mm - 170mm

Weight

0.59kg

* Total power consumed including driver
** Life span is calculated on expected average lifespan
*** Total depth measured from front of mounting surface to top of downlight

Product Cover

This product is covered by a 5-year limited warranty.

On-Site Warranty

Free On-Site Warranty is exclusive for M-World members for 3 years from the date of installation. We've got you covered for any associated labour and equipment hire costs. Terms and Conditions apply.
