C-Series High Powered Downlights
Product Information
Overview
The Commercial Series downlights boast remarkable luminous efficiency and sleek design. Featuring a concave front, reflector and lens optic fusion, and UGR <19, to reduce glare for pleasant ambiance. With adaptable mounting options and adjustable CCT (3000K, 4000K, 5700K), they suit various spaces like offices, schools, and hotels, offering flicker-free dimming.
Features
Multi CCT white, neutral white and warm white
Tech Specs
Total power consumed
13/16/18/20/25W
Lumen output
WW 2750lm | NW 3100lm | W 3000lm (at max wattage 25W)
Colour temperature
3000K (Warm White)
4000K (Neutral White)
5700K (White)
CRI
80
UGR
13W UGR<19, 16-25W UGR<22
Efficacy
WW 115lm/W | NW 135lm/W | W 130lm/W (at max wattage 25W)
Beam angle
60º
Dimmable
Non dimmable standard. Dimmable drivers available
Power supply
220-240VAC External, isolated driver
Power factor
0.9
Input Current
0.14A
Inrush Current
Up to 7 times input current
Frequency
50/60Hz
Average life
50,000hrs**
Operating Temperature
-20°C to +40°C
IP rating
IP54 front, IP40 rear
Dimensions
Ø 190mm x D 61mm*** | Cut-out 160mm - 170mm
Weight
0.59kg
* Total power consumed including driver
** Life span is calculated on expected average lifespan
*** Total depth measured from front of mounting surface to top of downlight
Product Cover
This product is covered by a 5-year limited warranty.
On-Site Warranty
Free On-Site Warranty is exclusive for Sparkys United members for 3 years from the date of installation. We've got you covered for any associated labour and equipment hire costs. Terms and Conditions apply.
