MR Backlit Panel 12X3 – ML-MRBPV3-12X3-M

ML-MRBPV3-12x3-M


Find a stockist Chat to Specialist

Resources

Downloads

Download Installation Instructions & Specs Download Case Study Download Case Study Download IES Photometric Files

Product Information

Overview

MR Backlit Panel UGR<19 3CCT series 12X3 (1195 x 295mm) 4000K, 5000K & 6000K colour temperature, 36W, non-dimmable, Flicker Free 220-240V driver with .6m flex & plug
Available in a full range of sizes (6×3, 6×6, 12×3, 12×6) and accessories to suit a variety of installations in the commercial space

Features

UGR<19

CRI90+

Slim Profile

What's in the box

1 x Panel per pack

Tech Specs

Total Power

36W*

MAX Lumen Output

3500lm (NW) | 3750lm (W) | 3600lm (CW)

Colour Temperature

4000K (NW) | 5000K (W) | 6000K (CW)

CRI

90+

COI

<3.3 (only at 4000K NW)***

Efficacy

97lm/W (NW) | 110lm/W (W) | 100lm/W (CW)

Input / Inrush Current

0.21A / Up to 7 times Input Voltage

IP Rating

IP40 (IP20 for rear)

Unified Glare Rating

UGR19

Dimmable

Non-dimmable standard, dimmable drivers available

Beam Angle

90°

Power Supply

220-240V flicker free driver (External)

Temperature Range ºC

-20º ~ +45ºC

Weight

1.96kg

Average Life

60,000hrs**

Dimensions

L 1195mm x W 295mm x D 25mm

*Total power consumed including driver
**Average life is calculated on expected average lifespan
***COI <3.3 is only applicable when set to 4000K (NW)

Product Cover

This product is covered by a 5-year limited warranty.
