NOX Highbay 80W-150W
ML-NOX-HB8-15-M

ML-NOX-HB8-15-M


Find a stockist Chat to Specialist

Product Information

Overview

Maximize efficiency with the NOX High Bay (V2), the ultimate 9-in-1 industrial LED lighting solution. Featuring 3 selectable wattages, 3 colours, and 3 beam angles, this high-performance fixture adapts to any environment—switch to a 60° beam for high-clearance warehouses or a 105° wide-angle for lower ceilings.

Whether you’re creating a cosy atmosphere in a café with warm white or a productive environment in a factory with cool white, the NOX V2 makes every job easier to suit. Now compatible only with the updated V2 sensor and memory-remote for effortless “point-and-shoot” programming, it is backed by M-Elec’s 7-year warranty for total peace of mind.

Features

Adjustable Beam - 60° / 90° / 105°

Power Selectable - 80W / 100W / 150W

3CCT

Improved Sensor and Memory Remote

What's in the box

1 x LED Highbay with Sensor Adapter

1 x AU Plug & 2m Flex

30cm Dimming Flex

Tech Specs

Total Power Consumed

Max 150W* (Selectable 80W / 100W / 150W)

Lumen Output

Up to 21,256lm

Efficacy

Up to 145lm/W

Colour Temperature

3000K / 4000K / 5700K

CRI

80+

Beam Angle

Adjustable - 60° / 90° / 105°

IP Rating

IP65

IK Rating

IK08

Temperature Range

-20°C to +50°C

Dimmable

Yes (1-10V) 30cm built in dimmable lead

Power Supply

120-277V AC flicker free driver

Frequency

50/60Hz

Power Factor

>0.9

Operating / Inrush Current

0.632A / Up to 7 times operating current

Average Life

50,000hrs**

Dimensions

Ø 310mm x H 171mm

Weight

2.12kg

* Total power consumed including driver
** Average life is calculated on expected average lifespan

Product Cover

This product is covered by a 7 Year limited warranty.

On-Site Warranty

Free On-Site Warranty is exclusive for Sparkys United members for 3 years from the date of installation. We've got you covered for any associated labour and equipment hire costs. Terms and Conditions apply.
